Heavy Knitted Display Fabric AA203 is a premium-quality polyester fabric designed for creating displays, pop-ups, and backdrops. It features a warp-knitted 2 bar weave method with yarn of 75D*75D, ensuring its strength and stability. This fabric has a weight of 230±10gsm and a thickness of 510±50μm, resulting in excellent opacity (≥85%) and whiteness (165±10). This fabric is ideal for sublimation printing with recommended fixation temperatures between 190-200℃ for 45 seconds. The fabric boasts high elasticity, with warp (10±3)% and weft (12±3)%, making it perfect for various irregular display forms. The fabric's colour is L:88.5±2.0; a:8.5±2.0; b:-19.5±2.0, producing vivid and accurate prints that are perfect for high-quality displays.
Base Material | 100% Polyester | DIN 60001, ASTM D7641 |
Yarn | 75D*40D*40D | DIN EN 2060, ASTM D1907 |
Weave Method | Warp-knitted 3 bar | --- |
Weight | 220±10gsm | ISO536 |
Thickness | 450±50μm | ISO534 |
Opacity | ≥80% | ISO2471 |
Whiteness | 160±10 | ISO11475 |
Color | L:88.0±2.0; a:9.0±2.0; b:-20.0±2.0 | --- |
Gloss[60°] | 4±2 | --- |
Elasticity | Warp:(6±3)% Weft:(3±2)% | Length*Width=200*50mm,Speed=100mm/min,Tension=20N |
Shrinkage | ≤2% | 200°C,45s |
Yellowing △E | ≤2 | 200°C,45s |
Flame Resistance | DIN 4102-1 B1, NFPA 701 | DIN 4102-1 B1, NFPA 701 |
Recommend Fixation Temperature | 190-200℃,45s | --- |
Yellowing Temperature | ≥210℃ | SUPRKC REX-C400,30s |
Size
Smooth Stretch Fabric AA301 Size | |||
Width | 1.60 m/2.60 m/3.20 m | Standard | DIN EN ISO 3759, ASTM D751-2006 |
Length | 50m | Standard | DIN EN ISO 3759, ASTM D751-2006 |
Compatible Inks
Compatible Inks | |
Dye-sub Transfer | Dye-sub Direct |
