Deco Display Fabric AA201 is a high-quality polyester fabric perfect for creating displays, pop-ups, and backdrops. It features a warp-knitted 3 bar weave method and a weight of 220±10gsm, ensuring its stability and consistency. The fabric's thickness of 450±50μm offers excellent opacity (≥80%) with a whiteness of 160±10, resulting in vivid and eye-catching prints. This fabric is perfect for sublimation printing with recommended fixation temperatures between 190-200℃ for 45 seconds. Furthermore, the fabric's elasticity of 3-5% makes it suitable for various irregular display forms. This ultra-high cost-effectiveness front light box fabric provides a flat fabric surface, stable and consistent printing quality, making it perfect for use in indoor and outdoor front display advertisements (under mild weather conditions) using the recommended printing methods of Dye-sub Direct and Dye-sub Transfer.
| Base Material | 100% Polyester | DIN 60001, ASTM D7641 |
| Yarn | 75D*40D*40D | DIN EN 2060, ASTM D1907 |
| Weave Method | Warp-knitted 3 bar | --- |
| Weight | 220±10gsm | ISO536 |
| Thickness | 450±50μm | ISO534 |
| Opacity | ≥80% | ISO2471 |
| Whiteness | 160±10 | ISO11475 |
| Color | L:88.0±2.0; a:9.0±2.0; b:-20.0±2.0 | --- |
| Gloss[60°] | 4±2 | --- |
| Elasticity | Warp:(6±3)% Weft:(3±2)% | Length*Width=200*50mm,Speed=100mm/min,Tension=20N |
| Shrinkage | ≤2% | 200°C，45s |
| Yellowing △E | ≤2 | 200°C，45s |
| Flame Resistance | DIN 4102-1 B1, NFPA 701 | DIN 4102-1 B1, NFPA 701 |
| Recommend Fixation Temperature | 190-200℃,45s | --- |
| Yellowing Temperature | ≥210℃ | SUPRKC REX-C400,30s |
Size
| Deco Display Fabric AA201 Size | |||
| Width | 1.60 m/2.60 m/3.20 m | Standard | DIN EN ISO 3759, ASTM D751-2006 |
| Length | 50m | Standard | DIN EN ISO 3759, ASTM D751-2006 |
Compatible Inks
| Compatible Inks | |
| Dye-sub Transfer | Dye-sub Direct |
